One Meter for Many Power Parameters
Our DC Digital Multi Function Meter gives you many readings in one device. We are Zhejiang Qunte New Energy Technology Co., Ltd., and we made this meter for panels, control cabinets, and automation lines. It measures voltage, current, active power, reactive power, apparent power, power factor, and frequency. The LCD screen shows all this data clearly. A customer in Dongguan used this meter on their injection molding machines. Operators could see each machine's real-time power. They could tell if the machine was running at its best. This helped them improve production efficiency.
High Accuracy in a Small Package
This DC Digital Multi Function Meter uses a high-accuracy chip. It measures with 0.5% accuracy. It can be installed on a 35mm DIN rail. It clips on next to circuit breakers. It saves space. It can also be panel-mounted. This gives you flexibility for different installation needs. The DC Digital Multi Function Meter fits many types of projects.
Easy to Connect to Your System
This DC Digital Multi Function Meter has an RS485 port. It supports Modbus-RTU protocol. You can connect it to a PLC, touch screen, or energy management system. You can read all measurement data from a computer. You can also set alarm thresholds. If voltage, current, or power goes above the set limit, it sends an alarm. For panel builders, automation makers, and factory maintenance teams, this meter is a useful tool.
Technical Specifications
|
Parameter |
Specification |
|
Rated Voltage |
AC220V, 50Hz/60Hz (single-phase or three-phase) |
|
Accuracy Class |
0.5 |
|
Measurement |
Voltage, current, active power, reactive power, apparent power, power factor, frequency |
|
Installation |
35mm DIN rail or panel mount |
|
Communication |
RS485, Modbus-RTU |
