Easy Remote Reading for Better Management
Our single remote meter helps you read power use from far away. We are Zhejiang Qunte New Energy Technology Co., Ltd., and we built this meter for people who want to check power data without going to the meter box. A customer from Africa once told us they had to walk a long way to read each meter. That took too much time. Now, with this single remote meter, they can get the data from their office. This saves time and makes work easier. You can add a pulse output to connect it to your system.
Strong and Safe Design You Can Trust
This single remote meter comes from our factory in Yueqing, where we focus on quality. We use good parts and a strong case. We test each meter for a long time before it leaves. This makes sure it works well for many years. It also has a feature to stop people from stealing power. If someone tries to tamper with it, the meter can detect it. This protects your money. It works in hot or cold weather, from -25℃ to 55℃. So you can use it in many places without worry.
Full Technical Details for Your Project
Here are the main specifications for this single remote meter. You can pick the right current size for your needs. The data is clear and easy to use.
Technical Specifications
|
Parameter |
Specification |
|
Rated Voltage |
AC220V 50Hz/60Hz |
|
Current Specifications |
2.5(10)A, 5(20)A, 10(40)A, 15(60)A, 20(80)A, 30(100)A |
|
Accuracy Class |
Class 1, Class 2 |
|
Operating Temperature |
-25℃ to +55℃ |
|
Power Consumption |
≤1.0W |
|
Starting Current |
≤0.004Ib |
|
Pulse Output |
Available upon request |
